8000 Series Scrapers

  • 3/8 plate back reinforced with 1.5 x 4 inch flat/3/4 x 8 curved grader blades
  • 425-22.5 tires/available with two or four rear tires/15k 10 bolt hub and spindles
  • 45 inch tall sides and back ¾ inch thick plate/with replacable side wear edges ar400 plate
  • Two 4×20 2.5 inch ram hydraulic cylinders

Weight:

  • Approximately 6900 – 15000 lbs

Other Options:

  • Rippers
  • available widths to 25 ft wide

Description

The model 8000 scrapers have 45 inch sides and back. They are heavy scrapers used as a feedlot scraper in pen cleaning and grooming, road construction, general farm work, and as an earth moving scraper.

Parts Manual

Please click the links below to download.

HITCH MANUAL

AXLE MANUAL

TONGUE MANUAL

Features/Benefits

  • 3/4 inch side plates
  • 15,000 lb hub & spindles
  • 425-22.5 tires
  • 4×20 hydraulic cylinders 2.5 inch rods
  • 2 inch hydraulic cylinder cross pins
  • Tilt standard
  • 8×8 square tube rear axle
  • Raised blade height 31 inches
  • Approximately  6900 – 15000 lbs

Applications

  • Building pads for Residential or Commercial sites
  • Maintaining Land fills
  • Land Leveling for Field Irrigation
  • Dam Construction
  • Building Wet Land Projects
  • Road Construction
  • Maintaining Feedlots
  • Water Ways and Terrace Channels
  • Building Lagoons and Runoff Pits
